    Thiết Bị Lưu Trữ NAS Synology DS1522+ Mã sản phẩm: DS1522+

    19,250,000 vnđ

    (Giá chưa VAT)
    • CPU: AMD Ryzen R1600
    • RAM: 8 GB DDR4 up to 32 GB
    • PCIe Expansion: 1 x Gen3 x2 network upgrade slot
    • LAN RJ-45: 4x 1GbE
    • Bảo hành: 3 năm.
CPU
CPU Model AMD Ryzen R1600
  CPU Quantity 1
  CPU Architecture 64-bit
  CPU Frequency 2-core 2.6 (base) / 3.1 (turbo) GHz
  Hardware Encryption Engine (AES-NI)
Memory
System Memory 8 GB DDR4 ECC SODIMM
  Memory Module Pre-installed 8 GB (8 GB x 1)
  Total Memory Slots 2
  Maximum Memory Capacity 32 GB (16 GB x 2)
  Notes
  • Synology reserves the right to replace memory modules with the same or higher frequency based on supplier's product life cycle status. Rest assured that the compatibility and stability have been strictly verified with the same benchmark to ensure identical performance.
  • Please select Synology memory modules for optimum compatibility and reliability. Synology will not provide complete product warranty or technical support if non-Synology memory modules are used for memory expansion.
  • For more information about the recommended memory configurations, please check the Hardware Installation Guide of your Synology product.
Storage
Drive Bays 5
  Maximum Drive Bays with Expansion Unit 15 (DX517 x 2)
  M.2 Drive Slots 2 (NVMe)
  Compatible Drive Type* (See all supported drives)
  • 3.5" SATA HDD
  • 2.5" SATA SSD
  • M.2 2280 NVMe SSD
  Hot Swappable Drive
  Notes "Compatible drive type" indicates drives that have been tested to be compatible with Synology products. This term does not indicate the maximum connection speed of each drive bay.
External Ports
RJ-45 1GbE LAN Port* 4 (with Link Aggregation / Failover support)
  USB 3.2 Gen 1 Port* 2
  eSATA Port 2
  Notes
  • This device's 1GbE LAN ports have a maximum transmission unit (MTU) size of 1,500 bytes.
  • The USB 3.0 standard was renamed to USB 3.2 Gen 1 by the USB Implementers Forum (USB-IF) in 2019.
PCIe
PCIe Expansion 1 x Gen3 x2 network upgrade slot
File System
Internal Drives
  • Btrfs
  • EXT4
  External Drives
  • Btrfs
  • EXT4
  • EXT3
  • FAT
  • NTFS
  • HFS+
  • exFAT
Appearance
Size (Height x Width x Depth) 166 mm x 230 mm x 223 mm
  Weight 2.7 kg
Others
System Fan 92 mm x 92 mm x 2 pcs
  Fan Speed Mode
  • Full-Speed Mode
  • Cool Mode
  • Quiet Mode
  Brightness Adjustable Front LED Indicators
  Power Recovery
  Noise Level* 22.90 dB(A)
  Scheduled Power On / Off
  Wake on LAN / WAN
  Power Supply Unit / Adapter 120 W
  AC Input Power Voltage 100V to 240V AC
  Power Frequency 50/60 Hz, Single Phase
  Power Consumption* 52.06 W (Access)
16.71 W (HDD Hibernation)
  British Thermal Unit 177.64 BTU/hr (Access)
57.02 BTU/hr (HDD Hibernation)
  Notes
  • For more information on how power consumption is measured, refer to this article.
  • Noise testing was conducted with the Synology system fully installed with Synology SATA HDDs and in an idle state. Two GRAS 40AE microphones are placed at a 1 m distance from the front and rear of the device. Background noise: 16.49-17.51 dB(A); Temperature: 24.25-25.75˚C; Humidity: 58.2-61.8%
Temperature
Operating Temperature 0°C to 40°C (32°F to 104°F)
  Storage Temperature -20°C to 60°C (-5°F to 140°F)
  Relative Humidity 5% to 95% RH
Certification
  • FCC
  • CE
  • BSMI
  • VCCI
  • RCM
  • UKCA
  • EAC
  • CCC
  • KC
Warranty
3-year hardware warranty, extendable to 5 years with EW201 or Extended Warranty Plus
  Notes
  • Availability varies by region. Before purchasing, please visit the official web pages of EW201/202 and Extended Warranty Plus for a list of eligible regions.
  • The warranty period starts from the purchase date as stated on your purchase receipt.
Environment
RoHS Compliant
Packaging Content
  • Main Unit X 1
  • Accessory Pack X 1
  • AC Power Adapter X 1
  • AC Power Cord X 1
  • RJ-45 LAN Cable X 2
  • Quick Installation Guide X 1
Optional Accessories
  • DDR4 ECC SODIMM: D4ES02-8G/D4ES01-16G
  • Expansion Units: DX517
  • 3.5" SATA HDD: HAT53002.5" SATA SSD: SAT5210
    M.2 2280 NVMe SSD: SNV3410
    10GbE Network Upgrade Module: E10G22-T1-Mini
    VisualStation: VS360HD
    Surveillance Device License Pack
  Notes
  • Certain items may not be available in your location. Please contact your local distributors for more information.
  • All memory modules will operate at the maximum frequency specified by the CPU manufacturer.
